Full-automatic

For tube / barΦ300mm- Φ1400mm

Features / Equipment :

● CNC band saw machine series apply to cutting large batch same material,  and the machine have the advantage of high cutting speed, high efficiency, work stable, energy saving and saving material. Can install a small beam clamping device.

● Machine adopt manual, full automatic and matches emergency off device function. hydraulic feed-in and tight clamping work. Step less, automatic power off and protect the equipment after finished cutting.

● Man-machine interface replace the function of  traditional control panel, digital setting, indicator lamp etc. Display the equipment state all the time. Operation instruction and parameter setting. all the setting are finished through the man-machine interface and  all the information are English, easy to operate.

● PLC (programmable logic controller) set the cutting / sawing whole process automatically.

● Feeding length of material was controlled by grating ruler tolerance less than 0.2 mm, can set 5 groups sawing parameter by once.

Technicaldata :

Modle GZ4230: Cuttingcapacity, Φ300mm

Modle GZ4240: Cuttingcapacity, Φ400mm

Modle GZ4250: Cuttingcapacity, Φ500mm

Modle GZ4260: Cuttingcapacity, Φ600mm

Modle GZ4270: Cuttingcapacity, Φ700mm

Modle GZ4280: Cuttingcapacity, Φ800mm

Modle GZ4290: Cuttingcapacity, Φ900mm

Modle GZ42100: Cuttingcapacity, Φ1000mm

Modle GZ42110: Cuttingcapacity, Φ1100mm

Modle GZ42120: Cuttingcapacity, Φ1200mm
